99.95% Pure Carbon Di Oxide gas.
Certifications: BIS Approved (IS 2878:2004) & CE certified.
Bodies CCOE/PESO approved.
High quality enamel paint.
Brass valve of wheel type with pressure relief discs.
Shells are Hydro tested to 250 bar.
High pressure Wire braided Hose.
Easy as well more economical to maintain & service.
Maximum visibility during Discharge.
No Electrical Conductivity Back to the operator.
No Thermal or Static Shock
|
MODEL
|
KFCRQ-2
|
|
|
|
Capacity
|
2 kg
|
Design
|
Bend pipe and Horn
|
|
Fire Rating
|
21B
|
Height (Approx.)
|
580 mm
|
|
Diameter (Approx.)
|
108±10 mm
|
Average Discharge Time
|
9 Sec.
|
|
Average Range of throw
|
2 m
|
Average Discharge
|
98%
|
|
Operating Temperature
|
-30 °C to +60 °C
|
Service/Max. service/Test Pressure
|
60 / 105 / 205 bar
|
|
Full Weight (Approx.)
|
9.5 or 10.5 kg
|
Empty Weight (Approx.)
|
7 or 8 kg
|
|
Shipping Weight (Approx.)
|
10 or 11 kg
|
Mounting Bracket
|
Wall bracket
|
|
Approvals
|
BIS
|
